Item

Unit

Parameter

Number of station

station

16 stations in part A, 10 stations in part B

Vial Output Efficiency

Pcs/hour

1350-1500

Size of Vial

Outer of Diameter(mm)

⌀12-24

Height of vial Body(mm)

25-80

Inner Diameter of Neck (mm)

⌀6-20

Outer Diameter of of Neck (mm)

Φ12-28

Speed-Regulating Motor

Type

YR100L-6

4

Power(KW)

1.5

Voltage(V)

380

Rotation(r/min)

adjustable

3.1

Machine Size(MM)

1600*1400*1600

180*110*190

Assemble Size(MM)

950*800

Weight for machine(KG)

1500

Air Pressure

(Reference Only)

Gas (Mpa)

0.012

Natural Gas (Mpa)

0.012

Liquid Gas (Mpa)

0.05

Oxygen (Mpa)

0.014

Air (Mpa)

0.02

Consumption

(Reference Only)

Gas (M³/hour)

2.5-3

Natural Gas (M³/hour)

1-1.2

Liquid Gas (M³/hour)

0.7-0.9

Oxyge (M³/hour)

5

Air (M³/hour)

6-9
