Item

Unit

Parameter

Number of station

station

12 stations in part A, 6 stations in part B

Vial Output Efficiency

Pcs/hour

>1200

Size of Vial

Outer of Diameter(mm)

⌀14-26

Height of vial Body(mm)

25-80

Inner Diameter of Neck (mm)

⌀6-20

Outer Diameter of of Neck (mm)

Φ12-28

Speed-Regulating Motor

Material Shaft(pcs)

Type

GD200A1R5G-4

4

Power(KW)

0.75

Voltage(V)

380

Rotation(r/min)

700

3.1

Machine Size(MM)

1400*1300*1440

180*110*190

Assemble Size(MM)

710*620

Weight for machine(KG)

950

Air Pressure

(Reference Only)

Gas (Mpa)

0.012

Natural Gas (Mpa)

0.012

Liquid Gas (Mpa)

0.05

Oxygen (Mpa)

0.014

Air (Mpa)

0.02

Consumption

(Reference Only)

Gap (M³/hour)

2.5-3

Natural Gas (M³/hour)

1-1.2

Liquid Gas (M³/hour)

0.7-0.9

Oxyge (M³/hour)

5

Air (M³/hour)

6-9
